Proven Success
Demonstrated high success rate in LBBAP procedures.1
CPS Locator 3D with UltiPace™ Pacing Lead and Helix Locking Tool
Accommodating Solutions
Three unique distal curves and two lengths provide enhanced variability and reach to accommodate various patient anatomy needs.2
Features of CPS Locator™ 3D Catheters
- Accommodates 6F stylet-driven leads, such as the UltiPace™ Pacing Lead, and provides better support with less risk of kinking.3
- The CPS Locator™ 3D is a single-use percutaneous catheter intended to introduce pacing or defibrillator leads.
- Each CPS Locator™ 3D Catheter offers a unique distal curve to accommodate various anatomies.
- The catheter is equipped with a hemostatic valve, and the distal tip is radiopaque to facilitate imaging under fluoroscopy.
- The Agilis HisPro™ Slitter is designed to ensure alignment and protect the lead during catheter slitting.
- Accommodate a 6F lead with a recommended minimum length of 58 cm for the 42 cm catheters and 65 cm for the 45 cm catheters.4
- The catheter has an inner diameter of 7 F, an outer diameter of 9 F, and the dilator is compatible with a 0.035” guidewire.
Ordering Information
| Model Number | Model Name | Overall Length (Cm) | Working Length (Cm) | Inner Diameter | Outer Diameter | Minimum Lead Length |
|---|---|---|---|---|---|---|
| DS2C100-42 | CPS Locator™ 3D, Small | 45 cm | 42 cm | 7 F (2.44 mm) | 9 F (3.00 mm) | 58 cm |
| DS2C200-42 | CPS Locator™ 3D, Medium | 45 cm | 42 cm | 7 F (2.44 mm) | 9 F (3.00 mm) | 58 cm |
| DS2C300-42 | CPS Locator™ 3D, Large | 45 cm | 42 cm | 7 F (2.44 mm) | 9 F (3.00 mm) | 58 cm |
| DS2C200-45 | CPS Locator™ 3D, Medium, Extra Long | 48 cm | 45 cm | 7 F (2.44 mm) | 9 F (3.00 mm) | 65 cm |
| DS2C300-45 | CPS Locator™ 3D, Large, Extra Long | 48 cm | 45 cm | 7 F (2.44 mm) | 9 F (3.00 mm) | 65 cm |
References
- Nair, D., & Atwater, B. (2023). Abstracts - 2023 - journal of arrhythmia - wiley online library. Wiley Online Library. https://onlinelibrary.wiley.com/doi/10.1002/joa3.12902
- Abbott. Data on File, Competitive Summary. Item: MAT-2302264 v1.0
- Burri, H., Jastrzebski, M., Cano, O., Curila, K., Pooter, J. de, Huang, W., Israel, C., Joza, J., Romero, J., Vernooy, K., Vijayaraman, P., Whinnett, Z., & Zanon, F. (2023). Ehra clinical consensus statement on conduction system pacing implantation: Executive summary. endorsed by the Asia-Pacific Heart Rhythm Society (APHRS), Canadian heart rhythm society (CHRS) and Latin-American heart rhythm society (LAHRS). Europace : European pacing, arrhythmias, and cardiac electrophysiology : journal of the working groups on cardiac pacing, arrhythmias, and cardiac cellular electrophysiology of the European Society of Cardiology. https://pubmed.ncbi.nlm.nih.gov/37061850/
- Data on file: 91112329
MAT-2500735 v1.0
