The Next Step in BTK Efficacy.
XIENCE Prime™ with BTK Indication Everolimus Eluting Peripheral Stent System is clinically proven for primary stenting of focal and long lesions and is engineered for outstanding performance.1,2
Advancing BTK efficacy
Clinically Proven
- Excellent long-term patency (angiographic binary in-stent restenosis (>50% stenosis)) of 85.2% and 98.7% limb salvage at 1 year.3,4
Pre-procedure4
Post-procedure4
12 months post-procedure4
Engineered for outstanding performance
- Leading MULTI-LINK stent design for exceptional acute performance, uncompromised radial force, and visibility5
- Coating technology for reliable expansion and controlled Everolimus drug release
- Innovative delivery system for excellent deliverability and confident deployment
Ordering Information
| Stent Diameter | XIENCE Prime™ with BTK Indication Peripheral Stent System | Post-Dilatation Limit | |||||||
|---|---|---|---|---|---|---|---|---|---|
| 8 | 12 | 15 | 18 | 23 | 28 | 33 | 38 | ||
| 2.25 mm | 1011706-08 | 1011706-12 | 1011706-15 | 1011706-18 | 1011706-23 | 1011706-28 | 3.25 mm | ||
| 2.5 mm | 1011707-08 | 1011707-12 | 1011707-15 | 1011707-18 | 1011707-23 | 1011707-28 | 1011707-33 | 1011707-38 | 3.25 mm |
| 2.75 mm | 1011708-08 | 1011708-12 | 1011708-15 | 1011708-18 | 1011708-23 | 1011708-28 | 1011708-33 | 1011708-38 | 3.75 mm |
| 3.0 mm | 1011709-08 | 1011709-12 | 1011709-15 | 1011709-18 | 1011709-23 | 1011709-28 | 1011709-33 | 1011709-38 | 3.75 mm |
| 3.5 mm | 1011710-08 | 1011710-12 | 1011710-15 | 1011710-18 | 1011710-23 | 1011710-28 | 1011710-33 | 1011710-38 | 4.5 mm |
| 4.0 mm | 1011711-08 | 1011711-12 | 1011711-15 | 1011711-18 | 1011711-23 | 1011711-28 | 1011711-33 | 1011711-38 | 4.5 mm |
References
- Bosiers, M et al. Randomized comparison of everolimus-eluting versus bare-metal stents in patients with critical limb ischemia and infrapopliteal arterial occlusive disease; J Vascular Surgery 2012;55:390-399.
- Bosier, M et al.Outcome of a drug eluted stent in longer below the knee lesions in patients with critical limb ischemia: J Vascular Surgery 2017;58(1):49-54
- M. Bosiers, DESTINY, VEITH 2010
- M. Bosiers, LINC 2011
- Tests and data on file at Abbott
MAT-2405570 V1.0
